model SL-2000-112 (2000W)
Main Features ◎ All in one design: Bi-direction inverter and charger ◎ Up to 12KW AC bypass capability ◎ -20℃~40℃ full load operation without derating
AC Output Voltage 120VAC ± 5% (≦ Continuous Power)
Rated Power 2000W
Surge Power 3200VA,
Output Waveform Pure Sine Wave (THD < 5%) Frequency 60Hz ± 0.1Hz DC Input Voltage 12V DC Input Voltage Range 9~17VDC ± 0.3V Efficiency > 90% (Peak)
Operating Temperature -20℃ ~ 40℃, Power De-rating from 40°C to 60°C
Storage Temperature -30℃ ~ 70℃
Safety UL458 & Supplement SA , FCC class B
Dimension (WxHxD) 321X203X349 mm / 12.64×7.99×13.74 inch
Weight (Net) 17.6kg
SL-2000 (2000W)
All in one design: Bi-direction inverter and charger
4 stage charging function with Max. 100A
Up to 12KW AC bypass capability (thru 2 legs , 50 Amp each)
Intelligent software for power management: Power sharing and generator function
Fan controls by load and temperature
-20oC~40oC full load operation without derating
UL458 with marine supplement , CSA 22.2 , FCC approved
Compact design (2000W @ 17.6 kg)
Accessory:
Remote controller CR-20
